Automatic Pipe Flange Welding Machine

Model: PFAWC-16Ba/24Ba/32Ba/48Ba/64Ba

Features
1. The automatic pipe flange welding machine offers excellent welding capacity (150-250 inch/day, which is four times higher than manual welding).
2. The machine is easy to operate.
3. The automatic pipe flange welding machine offers excellent surface forming.
4. It offers a welding compliance rate (without re-working for the skilled operator).
5. The automatic pipe flange welding offers good driving reliability.
Applications
Slip-on flange for the welding of the internal and external incidence angle
6. Classic product; widely used in industries like shipbuilding, mining, irrigation; suitable for welding pipe segments such as “flange + pipe + flange”; welding efficiency increased by more than 200%; one fixed-type wheel rotator; one movable wheel-supporting trolley; two movable welding trolleys; standard configuration: four Lincoln CV500 inverter welding power supplies; welding synchronously at inner and outer fillet with four MIG welding torches; operated with aluminum alloy control box.

Technical Parameters of the Automatic Pipe Flange Welding Machine (GTAWTIG)
Pipe Diameter Applicable: DN400/DN600/DN800/DN1200/DN1600
Pipe Wall Thickness Applicable: 3-20MM
Applicable Materials: Carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
Welding Line Applicable: Welding line of flange pipe
Machine Head System: One welding head with two welding guns at one end/two welding heads with four welding guns both at two ends
Driving System: Driven the motor of active idler wheel frame
Clamping System: Clamped by chain or contact roller
Bracket System: Two sets of motorized idler wheel to be set and it is adjustable according to the pipe length along the track
Speed Regulation Mode: VF stepless speed control system
Adjustment Mode: Electric cross regulator
Swaying System: A product of our patented technology, driven by step motor and oscillating adjusting with digital display
Control System: A product of our patented technology
Welding Procedure: GTAW/TIG
Welding Power: OEM products in China (or as per customers' demands)

As a China-based automatic pipe flange welding machine manufacturer and supplier, we provide a comprehensive range of products that includes pipe automatic welding machine, high speed pipe end beveling machine, slip-on flange and pipe fast fitting-up machine, and more.
